Heater

Stainless steel heating tube; external centralized heater, no direct contact with adsorbent, easy for maintenance.

Cooler

Air cooling or water cooling available upon request.

Filter

Pre-filter installed at the inlet of the dryer; post-filter installed at the outlet of the dryer.

Filter Element

Stainless steel filter element; long service life, high precision, cleanable and reusable.

Balancing Valve System

Equipped with a balancing valve system to maintain stable pressure during regeneration.

Heater Protection System

A backup temperature control system independent of the main PLC system is provided to prevent dry burning in case of PLC system failure or crash.

Control System

SIEMENS PLC control center, touch-screen operation and display, with fault diagnosis and alarm functions.

Regeneration Mode

Adopts a closed-loop constant-pressure regeneration cycle.

There is no need to release natural gas pressure in the regeneration tower, achieving zero natural gas emission. This reduces natural gas loss and is environmentally friendly.

Switching Mode

Manual, pneumatic and electric valve switching modes are available.
